Ionic Single Sign-On SSO


This solution allows you to setup Single Sign-On into . It allows setting up JWT SSO.You can allow your users to Single Sign-On into by verifying Identity with your existing compliant Identity Provider. This is done using JSON Web Token (JWT) tokens and it can be easily integrated with built in any framework or language.


Prerequisites

  • Add an Identity Provider. You can add any external IDP or directories (In case you don’t have IdP, you can use miniOrange as an Identity Provider)
  • Customizations support in mobile app to integrate sample code for enabling SSO.

Connect with External Source of Users


miniOrange provides user authentication from various external sources, which can be Directories (like ADFS, Microsoft Active Directory, Azure AD, OpenLDAP, Google, AWS Cognito etc), Identity Providers (like Shibboleth, Ping, Okta, OneLogin, KeyCloak), Databases (like MySQL, Maria DB, PostgreSQL) and many more.



Follow the Step-by-Step Guide given below for Ionic Single Sign-On (SSO)

1. Configure Ionic in miniOrange

  • Login to miniOrange Dashboard and click on Apps >> Add an Application.
  • Ionic Single Sign-On (SSO) add app

  • Click on Create App button in JWT box.
  • Ionic Single Sign-On SSO add app

  • Search for Ionic in the list, if you don't find Ionic in the list then, search for custom and you can set up your application via JWT App.
  • Ionic Single Sign-On SSO select app

  • Add details as shown below. In Identity Source select miniOrange. We’ll change it to Firebase later. The Redirect-URL should be the callback endpoint of your app where JWT token should be received for decoding and login.
  • Ionic Single Sign-On SSO configuration details

  • Click on Save button.
  • Click on Select dropdown >> Certificate beside your newly added app to download the certificate needed to verify the JWT token on your ionic app.
  • Ionic Single Sign-On SSO certificate

  • Click on Select dropdown >> Edit.
  • Copy the Single Sign-on URL in the Endpoints section and add it to your app. You can redirect Users to this URL after clicking on login. This will initiate their SSO flow.
  • Ionic Single Sign-On SSO endpoints url

  • Copy Client ID of the generated application and keep it with you for next the steps.
  • Now try entering this URL in an incognito window. You’ll see a login form like this:
  • miniOrange login form

  • Entering your miniOrange username and password here will issue a JWT token to your callback URL like this:
  • Ionic Single Sign-On callback url


2. Configure SSO in Ionic

  • Add the below SSO link in Ionic.
  • https://login.xecurify.com/moas/broker/login/jwt/?client_id=&redirect_uri=
  • You need to replace below values in URL:
  • customer-id Customer ID of your miniOrange account which can be found under settings menu.Refer image below.
    client-id Client Id of JWT application created above.
    redirect-url Configured Redirect URL against JWT application.
  • Get the Customer ID.
  • Go to the Settings section, present on the top right corner.
  • Copy the value mentioned against Customer Key.
  •  adfs sso customer key

  • On your Callback endpoint, you can read and parse the JWT token.
  • Structure of JSON Web Token (JWT): JSON Web Tokens consist of three parts separated by dots (.), which are:
    • Header: Contains the signature algorithm name used to sign the payload.
    • Payload: Contains user attributes.
    • Signature: Signature value of the payload. eg. xxxx.yyyyyyyyyyyy.zzzzzz
  • You will need to download a certificate from Apps and click Certificate link against your configured application. This certificate will be used for signature validation of the JWT response.
  •  adfs sso certificate link

  • Verify JSON web token: Click here to verify your JSON token.
  • Once you have added the link above on , you can verify the SSO setup by clicking a link.
  • On successful authentication, you will be redirected to configured Redirect or Callback URL with JWT token

3. Test SSO Configuration

Test SSO login to your Ionic account with miniOrange IdP:

    Using SP Initiated Login

    • Go to your Ionic URL, here you will be either asked to enter the username or click on the SSO link which will redirect you to miniOrange IdP Sign On Page.
    • Ionic Single Sign-On (SSO) login

    • Enter your miniOrange login credential and click on Login. You will be automatically logged in to your Ionic account.

    Using IDP Initiated Login

    • Login to miniOrange IdP using your credentials.
    • Ionic Single Sign-On (SSO) login

    • On the Dashboard, click on Ionic application which you have added, to verify SSO configuration.
    • Ionic Single Sign-On (SSO) verify configuration


    Not able to configure or test SSO?


    Contact us or email us at idpsupport@xecurify.com and we'll help you setting it up in no time.



4. Configure Your User Directory (Optional)

miniOrange provides user authentication from various external sources, which can be Directories (like ADFS, Microsoft Active Directory, Azure AD, OpenLDAP, Google, AWS Cognito etc), Identity Providers (like Okta, Shibboleth, Ping, OneLogin, KeyCloak), Databases (like MySQL, Maria DB, PostgreSQL) and many more. You can configure your existing directory/user store or add users in miniOrange.



  • To add your users in miniOrange there are 2 ways:
  • 1. Create User in miniOrange

    • Click on Users >> User List >> Add User.
    • Ionic VPN 2FA : Add user in miniOrange

    • Here, fill the user details without the password and then click on the Create User button.
    • Ionic MFA: Add user details

    • After successful user creation a notification message "An end user is added successfully" will be displayed at the top of the dashboard.
    • Ionic Two-Factor Authentication: Add user details

    • Click on On Boarding Status tab. Check the email, with the registered e-mail id and select action Send Activation Mail with Password Reset Link from Select Action dropdown list and then click on Apply button.
    • Ionic 2FA: Select email action

    • Now, Open your email id. Open the mail you get from miniOrange and then click on the link to set your account password.
    • On the next screen, enter the password and confirm password and then click on the Single Sign-On (SSO) reset password button.
    • Ionic Multi-Factor Authentication: Reset user password
    • Now, you can log in into miniOrange account by entering your credentials.

    2. Bulk Upload Users in miniOrange via Uploading CSV File.

    • Navigate to Users >> User List. Click on Add User button.
    • Ionic 2FA: Add users via bulk upload

    • In Bulk User Registration Download sample csv format from our console and edit this csv file according to the instructions.
    • Ionic Two-Factor authentication: Download sample csv file

    • To bulk upload users, choose the file make sure it is in comma separated .csv file format then click on Upload.
    • Ionic 2FA : Bulk upload user

    • After uploading the csv file successfully, you will see a success message with a link.
    • Click on that link you will see list of users to send activation mail. Select users to send activation mail and click on Send Activation Mail. An activation mail will be sent to the selected users.
  • Click on External Directories >> Add Directory in the left menu of the dashboard.
  • Ionic 2FA: Configure User Store

  • Select Directory type as AD/LDAP.
  • Ionic 2FA: Select AD/LDAP as user store

    1. STORE LDAP CONFIGURATION IN MINIORANGE: Choose this option if you want to keep your configuration in miniOrange. If active directory is behind a firewall, you will need to open the firewall to allow incoming requests to your AD.
    2. STORE LDAP CONFIGURATION ON PREMISE: Choose this option if you want to keep your configuration in your premise and only allow access to AD inside premises. You will have to download and install miniOrange gateway in your premise.
    3. Ionic Two-Factor Authentication : Select ad/ldap user store type

  • Enter LDAP Display Name and LDAP Identifier name.
  • Select Directory Type as Active Directory.
  • Enter the LDAP Server URL or IP Address against LDAP Server URL field.
  • Click on Test Connection button to verify if you have made a successful connection with your LDAP server.
  • Ionic MFA/2FA: Configure LDAP server URL Connection

  • In Active Directory, go to the properties of user containers/OU's and search for Distinguished Name attribute.
  • Ionic MFA: Configure user bind account domain name

  • Enter the valid Bind account Password.
  • Click on Test Bind Account Credentials button to verify your LDAP Bind credentials for LDAP connection.
  • Ionic MFA: Check bind account credentials

  • Search Base is the location in the directory where the search for a user begins. You will get this from the same place you got your Distinguished name.
  • Ionic 2FA : Configure user search base

  • Select a suitable Search filter from the drop down menu. To use custom Search Filter select "Write your Custom Filter" option and customize it accordingly.
  • Ionic MFA/2FA : Select user search filter

  • You can also configure following options while setting up AD. Enable Activate LDAP in order to authenticate users from AD/LDAP. Click on the Save button to add user store.
  • Ionic MFA : Activate LDAP options

    Here's the list of the attributes and what it does when we enable it. You can enable/disable accordingly.

    Attribute Description
    Activate LDAP All user authentications will be done with LDAP credentials if you Activate it
    Sync users in miniOrange Users will be created in miniOrange after authentication with LDAP
    Fallback Authentication If LDAP credentials fail then user will be authenticated through miniOrange
    Allow users to change password This allows your users to change their password. It updates the new credentials in your LDAP server
    Enable administrator login On enabling this, your miniOrange Administrator login authenticates using your LDAP server
    Show IdP to users If you enable this option, this IdP will be visible to users
    Send Configured Attributes If you enable this option, then only the attributes configured below will be sent in attributes at the time of login

  • Click on Save. After this, it will show you the list of User stores. Click on Test Connection to check whether you have enter valid details. For that, it will ask for username and password.
  • Ionic 2FA: Test AD/Ldap connection

  • On Successful connection with LDAP Server, a success message is shown.
  • Click on Test Attribute Mapping.
  • Ionic LDAP successful connection

  • Enter a valid Username. Then, click on Test. Mapped Attributes corresponding to the user are fetched.
  • Ionic MFA: Fetch mapped attributes for user

  • After successful Attribute Mapping Configuration, go back to the ldap configuration and enable Activate LDAP in order to authenticate users from AD/LDAP.
  • Refer our guide to setup LDAPS on windows server.

User Import and Provisioning from AD

  • Go to Settings >> Product Settings in the Customer Admin Account.
  • MFA/Two-Factor Authentication(2FA) for   miniOrange dashboard

  • Enable the "Enable User Auto Registration" option and click Save.
  • MFA/Two-Factor Authentication(2FA) for   Enable User Auto Registration

  • (Optional) To send a welcome email to all the end users that will be imported, enable the "Enable sending Welcome Emails after user registration" option and click Save.
  • MFA/Two-Factor Authentication(2FA) for   Enable sending Welcome Emails after user registration

  • From the Left-Side menu of the dashboard select Provisioning.
  • MFA/Two-Factor Authentication(2FA) for   User Sync/Provisioning

  • In Setup Provisioning tab select Active Directory in the Select Application Drop Down.
  • Toggle the Import Users tab, click on Save button.
  • MFA/Two-Factor Authentication(2FA) for   User Sync Active Directory Configuration

  • On the same section, switch to Import Users section.
  • Select Active Directory from the dropdown and click on the Import Users tab, to import all the users from Active Directory to miniOrange.
  • MFA/Two-Factor Authentication(2FA) for   User Sync Import Operation

  • You can view all the Users you have imports by selecting Users >> User List from Left Panel.
  • MFA/Two-Factor Authentication(2FA) for   User List

  • All the imported users will be auto registered.
  • These groups will be helpful in adding multiple 2FA policies on the applications.

miniOrange integrates with various external user sources such as directories, identity providers, and etc.

Not able to find your IdP or Need help setting it up?


Contact us or email us at idpsupport@xecurify.com and we'll help you setting it up in no time.



5. Single Logout (Optional)

If you want to ensure that all sessions (SP and IDP) for a user are properly closed, you can configure Single Logout with the steps below.

A. Configure miniOrange with IdP SLO endpoint:

  • Go to the Identity Provider tab and edit the configured Identity Provider.
  • Find the option Single Logout URL and configure the SLO URL provided by your IdP.
  •  adfs sso single logout url

B. Configure IdP with miniOrange SLO endpoint:

  • Configure your Identity Provider with below Single logout endpoint.
    https://login.xecurify.in/moas/broker/login/saml_logout/<your-customer-id>
  • You can find the SSO Binding option to configure the logout binding type to either REDIRECT or POST.

C. Configure your JWT application with SLO endpoint:

  • Configure your JWT application with below Single logout endpoint.
    https://login.xecurify.in/moas/broker/login/jwt/logout/<your-customer-id>?redirect_uri=<redirect-url>
